GB05 Series Wire-to-Board Connectors for Portable Outdoor Power Stations

In recent years, driven by the rapid growth of camping, self-driving travel, and emergency power demand, the portable outdoor power station market has continued to expand, evolving toward higher capacity and greater system integration.

As a key component of portable energy storage systems, these products typically integrate battery modules, Battery Management Systems (BMS), DC control boards, inverter modules, and various input/output interfaces. With increasing functional integration, internal space is becoming more constrained, and the electrical interconnection system plays an increasingly critical role in overall reliability and structural design.

Greenconn GB05 Series Wire-to-Board Connector Compact Interconnection Solution for Portable Energy Storage Systems

Interconnection Challenges in Outdoor Power Stations

• Stable power and signal transmission
Connections between battery modules, BMS, and control units must maintain stable power and signal transmission throughout charge and discharge cycles to ensure reliable monitoring and protection functions.

• Vibration and mechanical stress impact
During transportation and outdoor use, equipment may be subjected to continuous vibration and shock, which can lead to micro-motion at contact points and affect connection stability.

• High-density design in compact space
As system miniaturization progresses, PCB layout space becomes limited. Connectors must support high-density interconnection within confined space while maintaining assembly reliability.

GB05 Series Wire-to-Board Connector Solution

To address the interconnection requirements between battery modules, control boards, and interface systems in portable outdoor power stations, Greenconn GB05 Series wafer connectors provide stable support in both structural design and electrical performance.

• 2.00 mm pitch design: supports high-density PCB layouts
• TPA locking structure: prevents terminal displacement and improves vibration resistance
• 1000V AC withstand voltage: meets insulation requirements of power systems
• Operating temperature range -40°C to +125°C: adapts to complex outdoor environments

GB05 Series Wire-to-Board Connector Selection Reference

As portable outdoor power stations continue to evolve toward lighter weight and higher power density, the importance of internal interconnection systems continues to increase. The Greenconn GB05 Series connectors provide a compact and reliable wire-to-board interconnection solution between battery modules and control systems, helping improve long-term operational stability in complex environments.
