Specifications：
Pin unmber：24 Pin
Current Rating：5.0A
Voltage Rating：5V  AC
Contact Resistance：40mΩ
Insulation Resistance：100MΩMin
Dielectric Withstanding Voltage：100V AC/minute
Industry Standard : Type C
UL Flammability Rating : UL 94V-0
Operating Temperature：-40ºC to +85ºC
3D download：CUAD212-B001

Materials：
Contact Material：Copper Alloy
Insulation Material：PA 9T
